Technical parameters |
Product model |
SUQ |
Product code |
J7 |
Order number |
100072 |
Air pressure |
0.23MPa-0.25MPa |
Rotation speed |
350,000rpm-380,000rpm |
Noise |
≤60dB |
Atomizing water pressure |
0.3MPa |
Working water pressure |
0.20MPa-0.23MPa |
Water flow |
≥90ml/min |
Radial run-out |
jumping value of testing rod≤0.03mm |
Surface |
Titanium coating |
Water spray |
Triple water spray |
Chuck type |
Push button |
Cartridge | Open type |
Bearing | German bearings |
Sterilization |
Can be sterilized no more than 135 degree |
Other |
Anti-retraction system |
Adopt the world's top miniature bearings to ensure the durability of handpiece. Meanwhile, bearings also make the handpiece perform well in terms of noise and vibration.
It’s worth noting that the anti retraction system is designed to avoid the suction of residues or impurities into inner part of handpiece.By this way, it can effectively prevent damage to the mechanical performance of the handpiece and set up a solid defense against cross-infection.
Triple water spray has excellent performance in cooling effect, which avoid discomfort caused by excess heat of patient’s teeth during cutting.
Turn the situation of slowly screwing handpieces into 1 second quick connection. Under the medical principle of “one handpiece for individual patient”, the quick connecting handpiece greatly saves the time to replace handpieces for different patients.The handpiece is with 360 degree swiveling quick connection,which will enhance the dentist’s flexibility in direction turning during operation.
